Water Analysis Meter PCE-228-ICA incl. ISO calibration certificate

Name: Water Analysis Meter PCE-228-ICA incl. ISO calibration certificate
SKU: 19322
Availability: BackOrder

PCE-228-ICA

Availability : กรุณาติดต่อสอบถาม

หมวดหมู่: เครื่องวัดคุณภาพน้ำ

รายละเอียดเพิ่มเติม
บทวิจารณ์ (0)

PCE-228-ICA Water analysis meter incl. ISO calibration certificate�

For pH, redox and temperature/ Large, easy-to-read display / SD card memory (1 … 16 GB), stored data is saved as an Excel file / RS-232 interface and optional software for direct transfer to the PC

The water analysis meter PCE-228-ICA is a very easy-to-use pH / mV / °C / °F handheld instrument. The pH value and the temperature can be stored directly on the SD card (Excel file) or transferred directly from the water analysis meter to a PC via the RS-232 interface. For this we optionally offer a software and the suitable RS-232 interface cable as an accessory. Temperature compensation is either manual or automatic via the supplied temperature sensor.

All this allows a fast and reliable pH measurement. The water analysis meter has a three-point calibration, which is performed automatically. It can be determined with the combination meter, the pH, the temperature or the REDOX potential (ORP). For the latter measurement parameters, however, a REDOX electrode must also be ordered. Here we recommend the ORP electrode ORP-14. The water analysis meter is battery operated (6 x 1.5V batteries are included).

– Optimum price / performance ratio
– SD card memory (1 … 16 GB) – the stored data are saved directly as an Excel file on the SD card (no software needed for evaluation)
– RS-232 interface for online Data Transfer
– Measures pH, ORP & pH. Temperature
– High accuracy
– Large LCD display
– Robust housing
– Incl. PH electrode PE-03 and stainless steel temperature probe
– Automatic calibration
– Manual or automatic temperature compensation
– BNC connector
– Suitable for laboratory and on-site pH measurement
– Additional REDOX electrode
– Adjustable measuring rate
– Easy to operate
– Incl. ISO calibration certificate

Measuring range pH	0.00 … 14.00 pH
Resolution	0.01 pH
Accuracy	± (0.02 pH + 2d)

Measuring range redox	-1999 … 0 … 1999 mV (only possible with optional REDOX electrode)
Resolution	1 mV
Accuracy	± (0.5% + 2d)

Measuring range temperature	0 … 65°C / 32 … 149°F (only temp. Sensor)
Resolution	0.1°C / 0.18°F
Accuracy (@ 20°C / 68°F)	± 0.5°C / 0.9°F

Calibration	Automatic three-point calibration
Temperature Compensation	Automatically from 0 … 65°C / 32 … 149°F or manually between 0 … 100°C / 32 … 212°F with the temperature sensor removed
Electrode	PE-03 pH electrode, gel filled, 1 m cable and BNC plug
Temperature range	0 … 60°C / 32 … 140°F
Measuring rate	Adjustable from 1 second to 8 hours 59 minutes 59 seconds
Display	LC display 52 x 38 mm / 2 x 1.5 in
Data storage	Flexible via SD card memory 1 … 16 GB
Interface	RS-232
Software	Optional
Power supply	6 x 1.5V AA batteries / 9V power adapter (optional)
Environmental conditions	0 … 50°C / 32 … 122°F max. 85% rh
Dimensions	177 x 68 x 45 mm / 7 x 2.7 x 1.8 in�
Weight	490 g / 1.1 lbs
