The Vector 4D people counter thermal imager is the most advanced people counter in the world. The time of flight measurement method does not just allow people to be counted, but rather to recognize them. The people counter works completely anonymously and in compliance with data protection regulations.
The people counter recognizes people who move through the counting window at up to 5 m/s. The people counter not only recognizes the person, but can also distinguish whether it is an adult or a child. This makes the people counter an innovative aid, especially when analyzing customer groups. Furthermore, the people counter can recognize employees via a lanyard and exclude them from the people count.
The people counter is integrated into the network via the Ethernet interface. Power is supplied via PoE. The people counter can be read out via various IoT protocols. The integrated web server also offers a web interface for visualizing the measured values. Up to four Vector 4D Count people counters can be connected to one another via LAN.
– Mounting height: 2 … 4.5 m
– Detection range: 1.6 … 5.1 m
– Acquisition speed: max. 5 m/s
– Data protection-compliant people counting
– Employee recognition
– Height measurement
– Easy integration via MQTT, Rest API or HTTP Post
– HTML5 incl.
– Connection of 4 people counters possible
|2.5 m … 4.5m
|1.6 … 5.1 m
|195 mm x 110 mm x 32 mm
|Filtering the height measurement
|filtering by height when the counting line is exceeded
|Power Over Ethernet (PoE)
|IP interface Configuration
|IPV4 IP address: fixed or via DHCP IP
HTTPS: people counter, web service interface for data download and configuration
|Vector 4D incl. video camera for configuration and audit purposes. To protect privacy, this function must be deactivated in normal operation.
|for connection to external devices (I/O module)
|0°C … 40°C (non-condensing)
|-10°C … 50°C
